Hematology Analyzer Elite 3

Overview

The Hematology Analyzer Elite 3 is a compact and efficient 3-part differential hematology analyzer designed for accurate blood cell counting and analysis. It is widely used in hospitals, diagnostic centers, and clinical laboratories for routine complete blood count (CBC) testing. With advanced technology and reliable performance, it ensures fast and precise hematology results for better patient diagnosis and monitoring. Ultra Tech supplies brand-new diagnostic laboratory equipment in Bangladesh.

Key Features of Hematology Analyzer Elite 3

• 3-part differential hematology analysis
• High accuracy CBC results
• Fast testing with quick turnaround time
• User-friendly LCD interface
• Low sample volume requirement
• Automatic cleaning and maintenance system
• Stable and reliable performance
• Compact desktop design

Advantage of Hematology Analyzer Elite 3

• Only 3 reagents needed (Erba Diluent-Diff, Erba Lyse-Diff, Erba Cleaner), Enviroment-friendly (cyanide free)
• Built-in printer with 58 mm wide roll paper, full report with histograms
• USB interface for support: Host computer, Keyboard, External printers, Upgrade control SW, Data back-up, Hand-held barcode reader
• Usage of standard electronic and mechanic components
• Aperture made in technical ruby
• Easy handling
  • Full colour LCD touch-screen with high contrast ratio
  • Optional 8 languages (EN, FR, DE, CZ, PT, RU, ES, Indonesian)
  • User-friendly multilingual operating menu
  • Sample rotor, ensuring safe and easy sampling
  • Small-sized, low-maintenance needed

  Technical Specification of Hematology Analyzer Elite 3

  Measurement principles of Hematology Analyzer Elite 3:

  • Electrical impedance method
  • Photometry – LED based technology

  Parameters of Hematology Analyzer Elite 3:

  22 parameters: WBC, RBC, HGB, HCT, MCV, MCH, MCHC, PLT, LYM#, MON#, GRA#, LYM%, MON%, GRA%, RDW-SD, RDW-CV, PDW-SD, PDW-CV, MPV, PCT, P-LCC, P-LCR + 3 histograms (WBC-3part, RBC, PLT)

  Throughput: 80 tests / hour
  Sample volume: 25µl of whole blood using automatic sample holder
  Chambers: Dual chamber advanced system for higher accuracy & precision
  Clean Modes:

  • High voltage pulses on aperture
  • Chemical cleaning of the aperture using Erba Cleaner reagent
  • Back-flush using high-pressure

  Data capacity: 10 000 results with all histograms
  Data back-up method: USB mass storage device
  Software upgrade method: Via USB port (using USB mass storage)
  Built-in printer: Thermal printer module with 3 flexible options

  • Print full report with histograms
  • Only Print basic 8 parameters
  • Print from memory

  User interface & display:

  • Full colour LCD touch-screen with high contrast ratio
  • Status LED

  Dimensions (W x D x H): 320 mm x 260 mm x 365 mm

  Net Weight: 12 kg

Applications

• Complete Blood Count (CBC) testing
• Hospital clinical laboratories
• Diagnostic centers
• Emergency patient screening
• Routine health checkups
• Medical research labs

Technical Highlights

• 3-part WBC differential system
• Hemoglobin, RBC, WBC, Platelet analysis
• Automated sampling system
• Impedance measurement technology
• Internal quality control system
• Low reagent consumption
• High throughput performance

Power

The Elite 3 Hematology Analyzer operates on standard AC 220V / 50–60Hz power supply. It is designed for energy-efficient and stable operation in continuous laboratory environments.

Importance in Healthcare

The Hematology Analyzer Elite 3 plays a critical role in modern diagnostics by enabling early detection of diseases such as anemia, infections, blood disorders, and immune system conditions. Fast and accurate CBC results help doctors make timely clinical decisions, improving patient care and treatment outcomes.

FAQ -Elite 3

Q1: What is the Hematology Analyzer Elite 3 used for?

A: It is used for complete blood count (CBC) testing in clinical laboratories.

Q2: What type of analyzer is Elite 3?

A: It is a 3-part differential hematology analyzer.

Q3: Which parameters does it measure?

A: It measures RBC, WBC, Platelets, Hemoglobin, and related blood indices.

Q4: Is it suitable for small laboratories?

A: Yes, it is ideal for small to medium diagnostic laboratories.

Q5: Does Ultra Tech supply this machine?

A: Yes, Ultra Tech Bangladesh supplies brand-new Elite 3 hematology analyzers.
